ST4 series safety light curtain(TUV certified)

ST4 series safety light curtain(TUV certified)

...

product

Features:

◆ Comply with TUV Type 4 certification;

◆ Many specifications and models, wide range of application;

◆ Redundancy and self-check design to ensure that no error?signal sent to the controlled circuit when safety light curtain itself fails;

◆ Various fixing methods, easy to install

◆ Good immunity to the surrounding lights and electromagnetic;

◆ Good perfomance of anti-vibration,water and dust;

◆ Good performance and long service life;

◆ Intuitive indication of the sensor’s status, auxiliary alignment;

◆ Dual reverse pulses PNP safe output;

◆ EDM, auxiliary output function.

Parameters:

Protection range 0~12000mm
Protection height Light axis pitch×(beams-1)
Light axis pitch 7.5mm, 15mm, 30mm
Detection capability 14mm, 21mm, 36mm
Power supply DC24V
Power consumption ＜10W（no-load）
Loading current <200mA
Response time ≤18ms(beams≤64)
DC >99%
Certificate TUV
Performance level PL e (EN ISO 13849)
Sealing level IP65
Operation temp. –10°C ~ +55°C
Humidity 20°C, RH ≤85%
Immunity to light 10000Lux (Angle of incidence ≥5°)
Anti-vibration Frequency:10~55Hz, Amplitude:0.35mm
Impact resistance 10g, 16ms,1000times at X,Y,Z axis

Model:

H: protection height, L: sensor height

H1=50mm(The distance of 1st beam center to the bottom end cover)

?

Resolution 14mm Resolution 21mm Resolution 36mm
Model Beam H L Model Beam H L Model Beam H ?L
ST4-14-112 16 112 181 ST4-21-105 8 105 181 ST4-36-90 4 90 181
ST4-14-232 32 232 301 ST4-21-225 16 225 301 ST4-36-210 8 210 301
ST4-14-352 48 352 421 ST4-21-345 24 345 421 ST4-36-330 12 330 421
ST4-14-472 64 472 541 ST4-21-465 32 465 541 ST4-36-450 16 450 541
ST4-14-592 80 592 661 ST4-21-585 40 585 661 ST4-36-570 20 570 661
ST4-14-712 96 712 781 ST4-21-705 48 705 781 ST4-36-690 24 690 781
ST4-14-832 112 832 901 ST4-21-825 56 825 901 ST4-36-810 28 810 901
ST4-14-952 128 952 1021 ST4-21-945 64 945 1021 ST4-36-930 32 930 1021
ST4-14-1072 144 1072 1141 ST4-21-1065 72 1065 1141 ST4-36-1050 36 1050 1141
ST4-14-1192 160 1192 1261 ST4-21-1185 80 1185 1261 ST4-36-1170 40 1170 1261
ST4-14-1312 176 1312 1381 ST4-21-1305 88 1305 1381 ST4-36-1290 44 1290 1381
ST4-14-1432 192 1432 1501 ST4-21-1425 96 1425 1501 ST4-36-1410 48 1410 1501
ST4-14-1552 208 1552 1621 ST4-21-1545 104 1545 1621 ST4-36-1530 52 1530 1621
ST4-14-1672 224 1672 1741 ST4-21-1665 112 1665 1741 ST4-36-1650 56 1650 1741

?
